Magnetic Starter 15 Hp 3 Phase 460v For Electric Air Compressor

 Brand new 15 horsepower three-phase 460/480 volt magnetic starter control switch with steel housing. This is a great quality starter with a built-in overload that is adjustable from amps. It also has a manual reset button that can be switched to auto-reset. The steel housing has four 3/4" punch-out holes for incoming and outgoing wires. Also included are four rubber surround grommets for the 3/4" holes to protect the wires if needed. This starter does come with basic wiring instructions.

PROFESSIONAL INSTALLATION IS REQUIRED

Specifications:

Dimensions: 9" Tall, 5 1/2"  Wide, 51/2" Deep
Starter Rating: 15 HP, 460/480 Volt, 3 Phase
Amp Rating:  17-21 Amps / Adjustable

If you are using this starter on an air compressor, you will also need a pressure switch to control the starter. In this application, the pressure switch controls the On and Off of the starter according to the pressure setting of the pressure switch.

Due to this being an electrical item that can be installed incorrectly there is no warranty on this item after installation.
